Massey Ferguson BW13.71 Batwing® Rotary Cutters

Name: Massey Ferguson BW13.71 Batwing® Rotary Cutters
Brand: Massey Ferguson
Availability: OutOfStock

Call for Price

Get a Quote Get Financed Value a Trade Contact Us Book a Demo Get Directions Get Directions Print

Overview

BTHE ONE AND ONLY SINCE 1963

Rotary cutter owners and operators rated Woods® Batwing® cutter the #1 flex-wing cutter for cut quality in a blind study of the major brands in the category. The one and only since 1963, Woods® Batwing® cutter delivers unmatched cut quality, includes exclusive features for easy maintenance and tractor connection and is backed a 10-year gearbox warranty which includes parts, labor and seals.

Specifications

Model

BW13.71

Category Name

Implements

Year

2025

Sale Type

New

Manufacturer

Massey Ferguson

Options

Double row chain shielding; tandem spring arm suspension; pintel ring hitch; deck rings; LED lights

Hitch Type

Swivel clevis

Suspension

Spring-loaded axles

Weight (lbs)

7,860

Wheel Options

21 in. laminated, 25 in. severe-duty Ag, 25 in. severe-duty Ag foam-filled, 27 in. severe-duty Ag foam-filled, 29 in. used aircraft

Tractor PTO HP

70-300

Driveline Rating

CAT 6 CV main, CAT 5 wing

Blade Overlap (in)

Cutting Width (in)

162

Structure Warranty

2 years

Cutting Height (in)

2 to 15

Deck Thickness (in)

.135 in upper and lower

Tongue Weight (lbs)

2,700

Transport Width (in)

Blade Dimensions (in)

.5 x 4

Blade Tip Speed (fpm)

15,450 at 540 rpm; 16,300 at 1,000 rpm

Side Skirt Depth (in)

12.5

Cutting Area Shielding

Standard chain shielding

Gearbox Warranty (yrs)

Side Skirt Thickness (in)

0.25

Output Shaft Diameter (in)

2.38

Wing Flex Up/Down (degrees)

90 up, 22 down

Cutting Capacity Diameter (in)

Splitter/Wing Gearbox Rating (hp)

275 / 225 *Gearbox horsepower ratings listed are based on Woods’ field testing

features

Ideal for professional and contract cutting of heavy brush and trees up to 4 inches in diameter
Hinged metal gearbox shields open easily for maintenance
A 10-year gearbox warranty includes labor and seals under the Woods Cut Above™ Warranty for confidence in your purchase decision.
Woods Exclusive EZ-Change™ Blade System allows you to change blades in five easy steps with only a 3/4″ wrench.
Heavy-duty skid shoes prevent gouging and protect the deck
Strategically placed, welded baffles cut and distribute debris evenly
Features a double deck, built extra heavy to handle a host of rugged applications
Limited configuration available in reverse rotation
NOTE: All gearbox horsepower ratings listed in the following specifications are based on Woods’ field testing.

literature

Name	Link
Brochure	Download

Documents

Woods_BatwingCutters_Brochure_B04093.pdf
